PROFILING
ICC PROFILING
Download ready to use ICC color profiles compatible with all major printer brands and get useful information.
EPSON
Solvent
6000GS (onyx)
S60370 (onyx)
Aqueous/Pigment/Water-Base
Just in – EPSON P9500 with Onyx – Contact Us
3880
7600 Matte Black (onyx)
7600 Photo Black (onyx)
7900 Matte Black (onyx)
7900 Photo Black (onyx)
9600 Matte Black (onyx)
9600 Photo Black (onyx)
9800 Photo Black (onyx)
9800 Matte Black (onyx)
9900 Matte Black (onyx)
9900 Photo Black (onyx)
RGB – 7900/9900 Settings
– Allow whatever software you are printing with to manage colors
– Use the Photo Tex EP7900 (or 9900) UCHDmk_1400 profile
– In the printer’s dialogue screen, select Roll Paper, Watercolor Radiant White, Matte Black ink, Color Mode Off (No Color Management), Super Photo 1440 dpi, Super Microweave checked, High Speed Unchecked.
– Color density set to -18 (-20 results in a slightly faded image, -15 results with a bit of pooling in darker than middle gray tones), 5 for drying time.
Additional options:
9000/8000 series
1. Matte Black – Velvet Fine Art (preferred if you have a choice)
2. Photo Black – Luster 250
4880 – Try the Photo Quality Ink Jet Paper
11880
USE NO PROFILES
SETTINGS: ULTRA SMOOTH FINE ART ,COLOR – MATTE BLACK ,COLOR DENSITY – 30%
DRYING TIME 5 SECONDS, PAPER FEED – 0, SUCTION – STANDARD PAPER THICKNESS – 3
MODE – CUSTOM, GAMMA – 2.2, COLOR CONTROLS
BRIGHTNESS, CONTRAST, SATURATION, CYAN (–O), MAGENTA (+5), YELLOW (-5)
Epson Surecolor T7000 – Using Enhance Matte setting seems to work wonderfully.
EPSON COLORBURST
Epson COLORBURST (4800/7800/9800/6000S)
GS6000 Colorburst 9.3.3 Rip Profile : USE – Generic Vinyls – Adhesive Vinyls – Generic – Quality 1 – Bi-D – 1440×720 VS – 8P
HP
Photo Tex is now HP certified for the Latex Printers – see their ICC profiles at:
https://www.printos.com/ml/#/medialocator
Aqueous/Pigment/Water-Base
Z6100 – 42″
Z6100 – 60″
PhotoTex_HPL26500_792_ONX_600
PhotoTexS_HPL25500_789_CAL_600
PhotoTexS_HPL26500_792_ONX_600
PhotoTexS_HPL26500_792_CAL600 V9.2 may need to extract the profile (.calpatch file) from the zip before installing
PhotoTexS_HPL26500_792_CAL_600 V.9.1
PhotoTexS_HPL28500_792_ONX_600
PhotoTexS_HPL28500_792_CAL_600
***Please change heat setting to 190 Degrees or no more than 200 degrees on the L310/330/360/365/560/570***
Photo Tex Solvent (S, OPAS & EXS) for L310/330/360 ONYX
Photo Tex (Water Base , OPA, EX ) for L310/330/360 ONYX
Photo Tex (Water Base, OPA, EX) for L310/330/360 Caldera
HP L310/330/ 360 – otherwise try: HP matte adhesive vinyl profile, color looks great thru Onyx using Default CMYK as the input ICC & poster color as the rendering intent. While testing the roll further, ended up settling on 200 degrees for the curing temp at 10 pass.
Photo Tex (Water Base, OPA, EX) for HP L560 with Onyx
Photo Tex (Water Base,OPA,EX) for HP L570 with Onyx
Photo Tex (Water Base, OPA,EX) for HP L560 with Caldera
Photo Tex (Water Base, OPA,EX) for HP L570 with Caldera
Other Z series Settings to try:
1. HP Hahnemhle Textured Fine Art Paper (brightest red, darkest black)
2. HP Professional Matte Canvas
3. HP Premium Instant Dry Gloss Photo Paper
MIMAKI
JV33 260S Onyx 10.2.5
JV33 260S RasterLink Pro 5
Other option: . 3M 160 PAPER
720 X 720 3MW IJ 180C
UNI-PASS FOR MORE IN SATURATION
MUTOH FALCON
MUTOH
VJ-1638X for Photo Tex Solvent
MUTOH FALCON
1. CALENDERED VINYL SETTING HEATER 50 CELSIUS
2. LUSTER HEATER 50 CELSIUS
3. SEMI-GLOSS HEATER 50 CELSIUS
ROLAND
***** Use a 60 degree Carbide Blade for best contour cutting results ****
VersaCaMM:
_____________________________________________________________________________________________
Both the dual CMYK and the 6 color Below VS640. The 6 color would be loaded with CMYK, light cyan, light magenta and another Magenta & Cyan. The files are named as VS-640, but they cross-load with the 540 size as well. These are both for VersaWorks. Built in version 4.9.1, you should run the updater if at a lower version for those to come in ok.
PhotoTexS_VS640_MAX_2x4_VW_720
__________________________________________________________________________________________
Solvent (ONX – Onyx) (CAL-Caldera)
2020 – Photo Tex OPAS TRUE VIS VG 540-560 (versa works 6) CMYM & CYMKclmlkOr(8c)
PhotoTexOPAS_VG540-640_TV_4C_PS_900x600 – onx
PhotoTexOPAS_VG540-640_TV_4C_VWD_900x600 – onx
PhotoTexOPAS_VG540-640_TV_7C_PS_900x600 – onx
PhotoTexOPAS_VG540-640_TV_7C_VWD_900x600 – onx
PhotoTexS_VS540i_640i_MAX2_4C_VW_720
PhotoTexS_VS540i_640i_MAX2_6WMt_VW_720
PhotoTexS_VS540i_640i_MAX2_7C_VW_720
PhotoTexS_VS540i_640i_MAX2_7Mt_VW_720
PhotoTexS_VS540i_640i_MAX2_7W_VW_720
VS640 MAX_WMT6C VW 720C MYKcmWMt
SolJet:
SolJet ProIII XC540 MAX_2x6_VW_720CMYKcm x2
SolJet Pro 4 XR-640 series:
XR640_MAX2_7C_VW_720CMYKcmk
XR640_MAX2_7Mt_VW_720CMYKcmkMt
XR640_MAX2_6WMt_VW_720CMYKcmWMt
Roland RF-640 Versaworks with OPAS Photo Tex Opaque Solvent
Also printers like :
VP300 & VP540 – ORAJET 3640 MATTE WHITE paper setting we heard of very good results. MCVP Matte Calendared Vinyl on the 540 series also works well..
Roland GX Plotters – Carbide Blade 60 degree – Speed 7. Force 100. Turn on over travel. Keep sharp knife.
CANON
Canon ipfx100 printers (5100, 6100, 8100, 9100). – Try the Canon plain paper premium plain paper 80
Canon ipf6450 – “CANON FINE ART ENHANCED VELVET 225G” and printing by using File > Print , Printer manages Color, Color Space RGB, under Color use “Matching > Driver Matching Mode. Under Color: sometimes increase the Brightness +20 and the Contrast +20, but that may just be due to the digital file I’m printing.
